[nengo-user] nengo-user Digest, Vol 16, Issue 1 "Creating a STDP connection between two ensembles, (Claus Agerskov)"

[Claus Agerskov]

Hi Luc
Thank you for the response. The example file that you mentioned is correctly for a modulated connection. This example however is using an error signal that is computed by an error-ensemble. I am purely interested in using the STDP learning rule, as described a bit further down in the Bekolay paper. This learning rule was first described by Pfister and Gerstner and takes the parameters, t^pre, t^post1, t^pre2, A^-_2, A^-_3, tau_- and tau_x. The learning rule itself takes the form of

This learning rule is supposedly already implemented in Nengo, I am just not able to use it, as I am unaware of how to create a connection that is modulated by this rule and not the normal error-ensemble modulated connection.
Regards
Claus Agerskov

Date: Wed, 5 Nov 2014 12:54:39 +0100
Subject: nengo-user Digest, Vol 16,Issue 1 "Creating a STDP connection between two ensembles, (Claus Agerskov)"
From: lucvanneste37 at gmail.com
To: nengo-user at ctnsrv.uwaterloo.ca
CC: clausagerskov at hotmail.com

Hi Claus,
you can find a well working coding for such a connection in the 'Build a Brain' folder, chapter 6, 'learn.py'. It opens in wordpad.
Chapter 7.5. "Nengo: Advanced Modeling Methods", p284 in 'How to Build a Brain' by C. Eliasmith, gives you a lot more practical tips.
Success,
Luc Vanneste
